4X1 HDMI PRESENTATION SWITCHER

Brand :

18G HDMI 2.0 4×1 PRESENTATION SWITCHER WITH AUDIO EXTRACTION

The SW-H411A allows selection of four different sources (three HDMI inputs and one DisplayPort input) and will switch the selected video to the HDMI output. The audio is simultaneously de-embedded to an optical digital audio output and a balanced analog audio output. It supports video resolutions up to 4K x 2K@60Hz 4:4:4 8bit, 1080P, and 3D. In addition, there is a smart built-in EDID setting that can be selected by the 4-pin DIP switch on the rear panel.

Download the Brochure
The SW-H411A supports stereo and multichannel audio on the HDMI inputs. In addition to the audio embedded in the HDMI output stream, the audio is simultaneously de-embedded to an optical digital audio output and a balanced analog audio output. This switcher also features user friendly automatic switching and display control - no need for a separate control system. The switcher can also be manually controlled by the front panel buttons, IR remote, TCP/IP and RS232 command. The SW-H411A features a web UI for configuration and control. The Web UI can be set up to accessed from anywhere for easy support.

KEY FEATURES:

• Supports HDMI 2.0 and resolutions up to 4K@60Hz 4:4:4 8bit, 1080P, and 3D. • 18Gbps bandwidth and supports HDR10, HDR10+, Dolby Vision. • HDCP 2.3 compliant. • Video source auto-switching. • Automatic display control via CEC or RS232. • CEC control for display volume and ON/OFF. • Controllable via TCP/IP, RS232, IR. • Open API for third party control via TCP/IP and RS232. • Web UI for control and configuration. • Optical and balanced analog audio for audio de-embedding. • Smart EDID management for various application and customized setting.
